355nm Microchip Laser System of MC Series

Basic Information
Brand Name: CRYLINK
Certification: ISO9001
Model Number: 355nm 750ps Microchip Laser System of MCC Series
Minimum Order Quantity: 1
Price: custom
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detail Information
High Light:

750ps Microchip Laser


MCC Series Microchip Laser


Q Switched Microchip Laser

Product Description

355nm 750ps Microchip Laser System of MCC Series

MCC series microchip laser products have very ideal narrow pulse width, but also can achieve high single pulse energy. The product is a passive Q-switched solid-state laser based on semiconductor pump. The laser pulse is pure and tailless, the single pulse energy is stable, and the beam quality is good. The integrated design of semiconductor pump module and laser crystal makes the compact laser head easy to install and integrate. The system supports internal and external triggering. This series of products include four wavelengths of 1064nm, 532nm, 355nm and 266nm. The full sealing module inside the laser head can be used by customers for secondary development and application. The superior product performance index makes its application range very wide, especially in laser measurement, which can meet many different kinds of measurement needs, and also has excellent performance in the application of laser seeds. We can also provide 1064nm and 532nm isolators.(Download PDF)


Model Repetition Frequency Average Power Output Energy Pulse Width
CL355-100Hz-150μJ-MCC005 0.1 kHz 15 mW 150 uJ 700 ps
CL355-500Hz-90μJ-MCC006 0.5 kHz 45 mW 90 uJ 700 ps
CL355-1KHz-15μJ-MCC007 1 kHz 15 mW 15 uJ 700 ps
CL355-5KHz-10μJ-MCC008 5 kHz 50 mW 10 uJ 700 ps
CL355-10KHz-10μJ-MCC009 10 kHz 100 mW 10 uJ 700 ps


  • Pulse width up to 700ps
  • Pulse energy up to 80 μJ
  • External pump source fiber pump pulse energy can reach 500μJ
  • Repetition frequency up to 10kHz
  • Beam mode is TEM00
  • Fully sealed design, high reliability
  • Seed source
  • Micromachining
  • Laser ionization mass spectrometry
  • Laser ultrasonic inspection
  • Optical Parametric Oscillating Pump Source
  • Biomedical Science
  • Laser-induced fluorescence
  • Laser induced breakdown spectroscopy
