532nm 550ps Microchip Laser System of MCB Series

Basic Information
Brand Name: CRYLINK
Certification: ISO9001
Model Number: 532nm 550ps Microchip Laser System of MCB Series
Minimum Order Quantity: 1
Price: custom
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Description

532nm 550ps Microchip Laser System of MCB Series

MCB series microchip laser products have very ideal narrow pulse width, but also can achieve high single pulse energy. The product is a passive Q-switched solid-state laser based on semiconductor pump. The laser pulse is pure and tailless, the single pulse energy is stable, and the beam quality is good. The integrated design of semiconductor pump module and laser crystal makes the compact laser head easy to install and integrate. The system supports internal and external triggering. This series of products include four wavelengths of 1064nm, 532nm, 355nm and 266nm. The full sealing module inside the laser head can be used by customers for secondary development and application. The superior product performance index makes its application range very wide, especially in laser measurement, which can meet many different kinds of measurement needs, and also has excellent performance in the application of laser seeds.(Download PDF)

Model Repetition Frequency (kHz) Average Power (mW) Output Energy (uJ) Pulse Width (ps)
CL532-100Hz-80μJ-MCB007 0.1 8 80 500
CL532-100Hz-180μJ-MCB008 0.1 18 180 500
CL532-1KHz-70μJ-MCB009 1 70 180 500



  • Pulse width up to 500ps
  • Pulse energy up to 170μJ
  • External pump source fiber pump pulse
  • Charge energy up to 360μJ
  • Maximum repetition frequency up to 1kHz
  • Beam mode is TEM00
  • Fully sealed design, high reliability
  • Seed source
  • Micromachining
  • Biomedical Science
  • Laser ultrasonic inspection
  • Laser ionization mass spectrometry
  • Non-linear optical measurement
  • Laser-induced fluorescence
  • Laser induced breakdown spectroscopy
