High Light: | 520nm Solid State Laser,AWS Series Solid State Laser,Holographic Detection Solid State Laser |
---|
Our company has specially researched 520nm single-mode pigtail semiconductor light source for optical experiment and particle size measurement application, which has passed industrial design and batch production. The product has the advantages of small structure, stable power, convenient operation, etc., and meets the teaching and research and development needs of universities and scientific research institutions for red and green lasers.(Download PDF) 520nm Accurate Wavelength Laser System of AWS Series
Model
CL520-SIF(FP)-2mW-AWS001
Optical Parameter
Central Wavelength (nm)
520
Wavelength Tolerance (nm)
±6
Output Power (mW)
2
Line Width (nm)
1
Power Stability
±1.5% @8H
System Parameter
Power Adjustment Range
0~100%
Preheat Time (Min)
15
Output Method
FC/PC
Adapted Fiber
2.5µm,0.14NA
Power Input
100-240VAC, 50/60Hz
System Power Consumption (W)
<2
Storage Humidity (RH)
0~80%
Storage Temperature (℃)
-10~60
Operating Temperature (℃)
10~35
System Weight (Kg)
2
Laser Power Size (mm)
110×58×173
